Aperçu /Produits/maisons de conteneurs modulaires/AU Modern Standard Homes Modular Prefabricadas Prefabhouses Export Prefab and Expandable Containers

AU Modern Standard Homes Modular Prefabricadas Prefabhouses Export Prefab and Expandable Containers

2 sets
MOQ
AU Modern Standard Homes Modular Prefabricadas Prefabhouses Export Prefab and Expandable Containers
traits Galerie Description de produit Demandez une citation
traits
Caractéristiques
Warranty: 3 years
After-sale Service: Online technical support, Onsite Installation, Onsite Training, Onsite Inspection, Free spare parts, Return and Replacement, Other
Project Solution Capability: graphic design, 3D model design, total solution for projects, Cross Categories Consolidation, Others
Application: Living Room
Model Number: Global
Use: Carport, Hotel, House, Kiosk,Booth, Office, Sentry Box,Guard House, Shop, Toilet, Villa, Warehouse, Workshop,Plant, Hotel,House,Kiosk,Booth,Office,Sentry Box,Toilet,Warehouse,Workshop
Product Type: Container Houses
Design Style: Modern
Product name: expandable container house
Standard Size: L5850*W6300*H2500
Wall/Roof Material: Z Lock Type EPS sandwich Panel
Door: Steel security/Sliding door
Window: Aluminium Alloy Window
Lifespan: More Than 20 Years
Steel Frame: Galvanized light Steel Frame
Color: White,blue,green,brown, or customized
Electrical Device: Switch, Light, Socket, etc for customized standard
Informations de base
Model Number: Global
Conditions de paiement et expédition
Packaging Details: 1.Transparent film for expandable house 2.Bubble film for accessories 3.Paper protection for wall panel 4. units container house can fit in one 40HQ sea container
Supply Ability: 30 Set/Sets per Month
Description de produit
Product Description

Expandable container house/homes is not same with traditional squared container house, it is special designed temporary or permanent house. It not only can be used for office, shop, camp accommodation, rental housing, but also popular for flat granny house, resort house, private protal cabin, family living house and temporary modular house. Almost cover all the kinds of prefabricated houses or homes.
20ft 40ft Expandable Container House Specifications
External size:
20ft:L5900mm*W6600mm*H2500mm 40ft:11800mm*6600mm*2500mm
Packing size:
20ft:L5900*W2200mm*H2500mm 40ft:11800mm*2200mm*2500mm
Opened Area:
38 sqm / 70sqm
Service life
20 years
Color:
White,dark grey, gray, brown, or customized
Base Structure:
A:Frame beam:2.5mm galvanized
B:Top strap beam:2.5mm bending parts
C:Under frame:1.2mm(4*8galvanized square tube)
D:Roof decoration sheet:2.5mm galvanized bending parts
E:Folding part:2.5mm galvanized bending parts
Roof::
75mm z lock joined EPS sandwich panel,EPS density 14KG/M3,steel thickness 0.426mm
Wall:
50mm z lock joined EPS sandwich panel,EPS density 14KG/M3,steel thickness 0.426mm
Floor:
16mm thickness fireproof Mgo floor board
Door:
Inner doors:W850*H2100mm,aluminium sliding glass door with fly sreeen:W1800*2100mm. furnish with a handle lock with 3 keys
Window:
20ft: 9 pcs aluminium sliding windows W910*H900mm with fly screen40ft: 11 pcs aluminium sliding windows W910*H900mm with fly
screen
All windows glazed with double glass in a thickness of 5/9/5mm.
Connection kits
PVC Connection kits for ceiling, floor and walls.
Electricity
Switch,socket,lamp light,waterproof socket,distribution box.(All australia standard)
Optional accessories
Furniture,sabnitary,kitchen,A/C,electrical appliance for accomodation, office, dormitory, toliet, kitchen, bathroom, shower, steel
roof, cadding panels, decorative material,etc.
Advantage
(1)Fast installation:2 hours/set,save labor cost;
(2)Anti-rust:all material use hot glavanized steel;
(3)Waterproof:without wood ceiling,wall;
(4)Fireproof:Fire rating A grade
(5)Simple foundation:just need 12pcs concrete bolck foundation;
(6)wind-resistant(11 level) and anti-seismic(9 grade)
Design layout
We can design the drawings for you according to your requirements, you can decide the room layout including kitchen/ bathroom/bedroom / living room and how many rooms. Or we can design room layout according to your drawings! We will design a perfect layout for you!
20ft expandable container house:
40ft expandable container house:

20ft: two bed rooms+one bath room+one living room+one kitchen room

20ft: three bed rooms+one bath room+ one living room / one kitchen room

40ft: two bedrooms+one bath room+one living room+one kitchen room

40ft: two bedrooms+one bath room+one living room+one kitchen room
40ft: three bedrooms+one bathroom+ one living room + one kitchen cabinet
40ft: four bedrooms+one bathroom+ corridor
Option:
1, For size, we can supply both 20 feet and 40 feet to meet different customers requirement;
2, For layout, there will be 0-4 and more bedrooms to choose;
3, For frame color, you can choose any color you wanted;
4, For wall panel color, white gray, dark gray, blue and red are optional;
5, Water pipes and power switches are provided by the factory;
6, With aluminium double safety glass windows/ panel door / Australia standard power / led lights /mgo floor board /with shower room / bedroom/ kitchen room/ living room / water pipes ; We also could design space according to your drawing !

Advantages:
1. All frames are hot dipped galvanized, the floor and roof structure are all bolted together for easy removal and installation. And all steel fabric parts and the size of prefab house can be made according to clients' requirement.
2. The prefab house is low cost, durable structure, convenient relocation , and environment-protection,
3. The material of prefab house is light and easily to installation, no need special trained labors. one 37 square meter house five workers 2 hours finished, save manpower and time.
4. All the materials of prefab house can cycle-use, Meeting the require of environment protection in the world. Special is in the large-scale house projects in the developed region.
5. We used the high quality galvanized sheet and foam as the materials of the wall and roof .So the prefab house is good for fireproofing, water proofing, etc

Installation:
If your place is not flat to put this house, you also can built 12-16 wooden stakes or concrete foundation columns to support it.
Application:
Widely used for private living house, granny homes, garden porta cabin, temporary house when you build your family villa, resort house on beach or mountain, modular house for office or shop and so on.
Internal View


All the bathroom fittings, including shower room, toilet, wash basin ,mirror ,also kitchen room wash dishes and cupboard will be pre assembled in our factory, so will doors and windows. We also will do some special reinforce package to protect them when the pop up container homes in transportation.



Aluminium sliding window, double glazed glass thickness 5/9/5mm with fly screenSize: 900*910mm or customizedColour: white / black / cream etc customized




L shaped kitchen cabinet with sink and tap. * More handlebars for you to choose from


All the system for the expandable container house will be prefabricated in our factory, no matter wire, distribution box, or switches and socket, we can supply different standard to meet different countries' requirement.



The house will be folded to save space during transportation and you can be installed quickly and easily, it only need two hours!
More Details
Packing and Delivery
PACKAGE : Knock down package, size as 20GP. 2 set in 40HQ or 40 top open container
DELIVERY TIME : 15-20 days after confirming order,detail delivery date should be decided according to production season and order quantity.
Our Plant
Linyi Ocean Import&Export Co.,LTD,a container house,coolroom sandwich panel&Aluminium windows and doors manufacturer.Our group factory is located in Shandong .We have more than 10 year experience. We export to Australia all the year round.
Thanks for visiting our products!And please feel free to contact us anytime!Any inquiry would get replied within 2 hours in working hours!
https://lyocean.en.alibaba.com
Tel:0086-13355082909
Email: salelyocean@163.com
Related Products
Folding Container House
Flat Pack Container House
Z Lock Type EPS Sandwich Panel
Aluminum sliding window / Door
FAQ
1.Q: Are you a factory or trading company?
A: A:Yes, Linyi ocean is a 100% professional manufacturer located in Linyi city,Shandong province.
2.Q. Can I visit your company?
A: Yes, we welcome you to visit us any time. We are only 10 minutes from the Linyi city airport.
1 hour from Qingdao Liuting International Airport.
1.5 hours from Shanghai Pudong International Airport.
2.5 hours from Guangzhou Baiyun International Airport.
3.Q: Could you please design a new and unique prefab house for me?
A:Absolutely! We are able to provide you with not only construction scheme and structural drawings, but landscape design! Besides, detailed drawings and 3D models are surely included. One-stop service is our outstanding superiority with no doubt.
4.Q: What should I provide to build a steel prefab house?
A: So easy! Sketch drawing would be a better reference for us. However, you will never mind if you don't have any. Simply notify us of your requirements, such as the area, usage and the stores of the house. Before long, you'll possess an amazing design.
5.Q: How could I ensure the cost of building a steel prefab house?
A: Firstly, the designing scheme should be accepted. Then, the kinds of building materials should be confirmed since different types and qualities make various prices. After that, we will send you a detailed quotation.
6.Q: How Long does it take to build a prefab container house?
A: It depends on the size of the house. Generally, the construction period is a 1 container house by a construction team of 4 people. It only costs 4 hours to build a container house.
7.Q: Is it difficult to build a prefab house?
A: totally not, you can build the house independently according to the construction drawings as long as you know how to use an electric tool. Or I can provide a video show you how to fast install a house.
8.Q: How long is your delivery time?
A: Generally it is within 15 days after getting the deposit and final drawing, definitely according to quantity and house style.
9.Q: Can I ask for the toilet, kitchen, decoration, solar heater and so on.
A: Absolutely! We are turnkey house solution supplier, we have an engineer to design the one
stop house also reliable suppliers for those fittings.
10. Q: How can I get the quotation for the project?
A: If you have drawn, we can offer you our quotation according to your drawing. If you have no design, Our engineer makes your idea to a real house and
will design some drawings for you to confirm. And then offer you a quotation under your material demand and drawing.
11. Q: Can I place the order directly?
A: Our entire house is accepted customized and the price is under the final material, the price listed on the page is only for reference. Please contact us for more detail, we only accept the order under final the drawing and
material. Thanks for your understand.
